SPECIFICATIONS
YOUR BENEFITS
Highest reliability for stable operation and long product lifespan
Reduced risk of chemical attacks and oil breakdown by diluting chemical vapors with larger oil chamber
Slowing down corrosion by cool running operation
Provides a measure of protection from sublimed chemical vapors with coating on pump module and oil case
Extended oil change intervals for less maitenance costs
Less oil consumption by cool running operation
Extended usability of oil due to high dilution effect by larger oil chamber
LOW NOISE LEVEL
Exceptionally quiet for undisturbed work.
FORCED OIL LUBRICATION
Ensures moving parts are bathed in fresh oil. Equilibrates temperature, minimizes oil breakdown, and prolongs mechanical life.
ANTI-SUCK BACK VALVE
Prevents oil from being sucked into application in the event of a power failure.
GAS BALLAST
Minimizes entrained chemicals in pump oil. Protects pump from condensable liquids from application such as water, acetyl nitrile, etc.
cUL AND CE CERTIFIED
Compliance with local regulations and safety directives for safety operation.
SIZED TO FIT YOUR APPLICATION
Modern and compact design to fit different applications and performance requirements.
DUAL VOLTAGE MOTOR
Dual voltage motors meet IP44 standard. Motors of CRVpro 4,6,8 are switchable from 115V to 240V for global use excluding 100V and 200V pump versions. Each pump includes power cord suitable for country use.
List Price $2,970.00
Discount Price $2,820.00
List Price $3,386.00
Discount Price $3,215.00
List Price $3,713.00
Discount Price $3,530.00
List Price $4,623.00
Discount Price $4,390.00
List Price $6,188.00
Discount Price $5,880.00
List Price $7,738.00
Discount Price $7,350.00
TECHNICAL DATA
PARAMETER UNIT CRVpro4 CRVpro4 CRVpro8 CRVpro16 CRVpro24 CRVpro30
Free air displacement
- @ 50 Hz m3/h (I/min) 4 (67) 6(100) 8 (133) 18.3 (305) 26.2 (436) 33.1 (551)
- @ 60 Hz CFM (1/min) 2.8 (78) 4.2 (118) 5.6 (158) 12.8 (363) 18.3 (519) 22.1 (627)
Ultimate Pressure
- Without gas ballast partial mbar (Torr) 5X10-4 (4X10-4) 3X10-4 (2X10-4)
- Without gas ballast total mbar (Torr) 2X10-3 (1.5X10-3) 3X10-4 (2x10-3)
- With gas ballast total mbar (Torr) 7X10-2 (5X10-2) 6X10-3 (5X10-3)
Connection flanges NW 16 25
Hose connection, inlet* ID Tubing 5/8" - 3/4" (16-19 mm) 3/4" (19 mm)
Ambient temperature °C 10-40
Noise level (50 Hz) dB (A) 50 55
Oil capacity ml 1150 1000 2400 2200 2100
Motor speed rpm 50/60 Hz 1450/1740 1450/1750
Weight kg (lbs.) 21 (46.3) 22 (48.5) 22.5 (49.6) 37 (81.6) 38.5 (84.9) 39.5 (87)
Motor power kW 50/60 Hz 0.37/0.4 0.7/0.85
Dimensions L x W x H mm (inch) 463/157/230 (18.2/6.1/9.1)** 569/206/289 (22.4/8.1/11.4)
*Requires a hose barb adapter. Included in pump versions with suffix -01.
** Without handle.
